The frame is strong enough to make sure the the material would not be come out.
The molds could be open in 1second to make sure the cell in the foam is uniform.
The temperature difference could be controlled in ±1℃, so that the color of the sheet is uniform.
We use PLC to control the system and the whole process could be automatic or manual controlled.
| No. | Main technical parameters | Discription |
| 1. | Clamping force | 700 Tons |
| 2. | Platen size | 1100 x 1350 mm |
| 3. | Layers | 6 |
| 4. | Distance between layers | 150 mm |
| 5. | Distance between columns | 1400 mm |
| 6. | Diameter of cylinder | 26 inch / φ650 mm |
| 7. | Heating method | steam / hot oil/ electrical pipes |
| 8. | Control method | auto control by PLC |
| 9. | Temperature difference | ± 1 ℃ |
| 10. | Temperature range | Max. 180 ℃ |
1. Optimized thermal insulating board
2. Synchronizing mechanism
3. Auto-loading and unloading system
4.Heating oil boiler
5. Steam temperature-control system
